Researchers Measure Microwave Phase with 0.1 Degree Resolution

A sensitivity enhancement exceeding 25 dB has been achieved in microwave metrology using a new Rydberg-atom-based system. Jun-Rong Chen of the Beijing Institute of Radio Measurement and colleagues from University of Chinese Academy of Sciences, Zhejiang University, Institute of System Engineering, and Harbin Institute of Technology demonstrated a microwave Mach-Zehnder-type interferometer with a dual-local-oscillator configuration, enabling direct phase retrieval. The system delivers a phase resolution better than 0.1° and a propagation-distance precision below 20μm at 5.7GHz, alongside full 360° phase coverage.

Jun-Rong Chen and colleagues have created a method for measuring microwave fields with greater precision using Rydberg atoms and a dual-local-oscillator setup. The system improves upon existing techniques by simultaneously increasing sensitivity and simplifying the experimental design. The key lies in establishing two pathways for microwave signals within the Rydberg medium, allowing for direct retrieval of the signal’s phase and avoiding the need for complex optical arrangements and signal processing.

This direct phase retrieval is crucial as traditional methods often rely on indirect measurements susceptible to noise and calibration errors. The Rydberg atoms, when excited by microwave radiation, exhibit a strong and predictable response, making them ideal transducers for these measurements.

Jun-Rong Chen and colleagues have developed a technique for precisely measuring microwave fields, vital for applications like wireless communications and radar systems. Existing methods often struggle to simultaneously achieve high accuracy, broad bandwidth, and simplicity, but this approach overcomes these limitations by utilising Rydberg atoms as extremely sensitive detectors. The team constructed a Rydberg-atom-based Mach-Zehnder interferometer, a device that splits and recombines microwave signals to reveal subtle changes, using two local oscillators to create two pathways for the microwave signal.

This design allows for direct measurement of the signal’s phase, achieving a resolution better than 0.1° and a sensitivity enhancement exceeding 25 dB, effectively converting subtle shifts in the microwave signal into measurable changes. The implications for advanced communication systems are significant, potentially enabling more efficient spectrum utilisation and increased data transmission rates. Furthermore, improved radar systems could benefit from enhanced target detection and resolution.

Rydberg atoms enable high-resolution microwave signal characterisation with enhanced sensitivity

A sensitivity enhancement exceeding 25 dB has been achieved in microwave metrology, representing a substantial improvement over existing techniques limited by lower sensitivity and complex setups. The conversion of subtle amplitude variations into pronounced phase responses made this possible, allowing detection of sharply weaker microwave signals previously undetectable without substantial amplification and sophisticated signal processing.

Rydberg atoms, with their large principal quantum numbers, possess an exaggerated response to external fields, including microwaves, making them exceptionally sensitive probes. This sensitivity stems from the weak binding of valence electrons in highly excited Rydberg states, leading to a significant dipole moment and enhanced interaction with electromagnetic radiation.

Harbin Institute of Technology researchers demonstrated a propagation-distance precision below 20 micrometres at 5.7GHz, alongside a polarization-angle resolution exceeding 0.1 degrees. The Rydberg-atom-based Mach-Zehnder interferometer employs a dual-local-oscillator configuration, establishing two coherent pathways within the Rydberg medium and enabling direct phase retrieval without complex optical setups or lock-in detection. A reconfigurable dual-local-oscillator architecture and the key enhancement technique converting weak amplitude variations into pronounced phase responses enable unambiguous full 360-degree phase coverage.

The dual-local-oscillator configuration is critical; it provides a stable reference phase, allowing for precise determination of the phase shift induced by the microwave signal under test. While these results show a scalable framework for multifunctional high-precision microwave metrology, current measurements do not yet demonstrate performance in realistic, noisy environments or address the challenges of miniaturisation required for widespread deployment. Future work will likely focus on mitigating environmental noise and developing integrated Rydberg atom sources for portable applications.

Achieving simultaneous high resolution and broad range in microwave phase metrology

Continuous innovation in microwave metrology is driven by the demand for increasingly sophisticated wireless communication and radar systems. The new Rydberg-atom interferometer offers a compelling pathway to multifunctional sensing, but a persistent challenge remains: balancing performance characteristics against system complexity. Meyer et al. noted that previous Rydberg-atom approaches often forced compromises between achieving high phase resolution and maintaining a broad measurement range.

Traditional methods often relied on trade-offs between sensitivity and dynamic range, limiting their applicability in diverse scenarios. For instance, increasing the interaction time between the microwave field and the Rydberg atoms can enhance sensitivity but also narrows the measurable frequency range.

The interferometer nonetheless delivers a significant advance by achieving both high phase resolution, better than 0.1 degrees, and full 360-degree phase coverage. This is accomplished through a clever dual-local-oscillator design, enhancing sensitivity by over 25 decibels and enabling precise measurements of both microwave signal distance and polarization. Such multifunctional capability promises improvements across diverse fields, from wireless communication to radar systems. The ability to measure multiple parameters simultaneously reduces the need for separate instruments and calibrations, streamlining the measurement process and improving overall accuracy. The 5.7GHz frequency used in these experiments is within a commonly used band for wireless communication, highlighting the potential for immediate application in this field. Further research could explore the performance of this system at higher frequencies and with more complex microwave waveforms.

The researchers demonstrated a Rydberg-atom-based microwave interferometer capable of measuring the phase of microwave fields with a resolution exceeding 0.1 degrees and full 360-degree coverage. This performance represents an improvement over previous methods which often traded resolution for measurement range. The system achieves enhanced sensitivity, exceeding 25 dB, and simultaneously measures microwave propagation distance to within 20μm and polarization angle to better than 0.1 degrees at 5.7GHz. The authors suggest future work may investigate performance at higher frequencies and with more complex signals.
