Exceeding 84 megaprames per second, a new optical system controls ultracold atoms representing a sharp leap in speed and resolution. Alexander Dennisovich Deters from Harvard University and colleagues developed a dispersive spatial light modulator, a device which shapes light to manipulate the atoms, achieving this record frame rate alongside an intensity resolution of 10^-3. This system manipulates ultracold atoms at speeds exceeding eighty-four million frames per second.

It precisely controls atom arrangement through dispersive spatial light modulation mapping frequency to position in two dimensions. The capability unlocks advanced quantum simulations and expands research into fundamental physics by enabling complex atom arrangements with minimal disruption.

At Harvard University, Alexander Dennisovich Deters and colleagues unveiled an optical system capable of manipulating ultracold atoms with unprecedented speed and precision, exceeding eighty-four million operations per second. The advancement builds upon programmable arrays of these atoms, a leading technology for quantum computing and simulating complex physical systems like those found in materials science. A key challenge lies in controlling many interacting quantum states requiring sophisticated optical design.

The team addressed this by developing a dispersive spatial light modulator, essentially a high-speed dimmer switch for laser beams that shapes light to control atom arrangement. Consider modelling traffic flow on a gridlocked city street but directing individual atoms with incredible accuracy. The new device achieves an intensity resolution of 10^-3 alongside its record frame rate, enabling Alexander Dennisovich Deters and colleagues to create intricate arrangements of ultracold atoms while minimising unwanted disturbances.

Rapid Optical Control Enables Advanced Ultracold Atom Manipulation and Quantum Simulation

Exceeding 84 megapframes per second, a rate over ten times faster than previous liquid crystal spatial light modulators operating at approximately one kilohertz, the new dispersive system unlocks dynamic control previously unattainable in ultracold atom experiments. This leap in frame rate allows for fully programmable Hubbard models which mimic materials’ behaviour by controlling interactions between atoms with tailored optical fields.

The enhanced speed also enables rapid permutations of optical tweezers, tiny laser beams used to hold individual atoms, facilitating exploration of high-rate error correction codes vital for building stable quantum computers and decoupling design constraints from complex atomic arrangements.

The researchers have demonstrated an optical system capable of exceeding 84 megapframes per second when manipulating ultracold atoms. Building more complex simulations of materials governed by the Hubbard model, a mathematical description of electron interactions within solids, relies on this increased speed. The team achieved intensity resolution of 10^-3, allowing precise control over atomic arrangements alongside spatial resolution encompassing $83 × $52 beam waists. However, only $11 × $52 are accessible through a single modulator operating at 40GHz.

This architecture also enables rapid rearrangement of individual atom positions using optical tweezers and exploration of error correction codes with permutation rates previously unattainable. Numerical validation confirms their scheme can dynamically adjust chemical potentials and tunneling amplitudes to mimic material behaviours. These experiments currently involve relatively small numbers of atoms and scaling up while maintaining coherence remains a strong hurdle towards practical quantum simulation.

High-speed patterned illumination of ultracold atoms via dispersive spatial modulation

A dispersive spatial light modulator served as the core technology, essentially a high-speed dimmer switch for laser beams, to sculpt and direct light onto ultracold atoms. This technique allows precise control over both beam brightness and shape individually. Rapid alteration is key; by mapping frequency to position in two dimensions, the system generates complex arrangements whilst minimising unwanted heating effects on sensitive atomic systems. This approach bypasses limitations inherent in conventional optical trapping methods which often struggle to balance speed, resolution, and stability when manipulating many atoms simultaneously.

High-speed patterned light unlocks dynamic ultracold atom manipulation

Precisely manipulating ultracold atoms opens new avenues for simulating complex quantum systems but achieving truly dynamic control presents ongoing challenges as scientists strive to balance speed, resolution, and minimise unwanted atomic heating during experimentation. While this team demonstrates a system comparable in scale to previous designs utilising digital micromirror devices or liquid crystal modulators, maintaining homogeneity across larger arrays remains difficult. Nevertheless, the demonstrated precision, achieving intensity control to one part in a thousand, and speed exceeding eighty-four million optical pattern changes per second enables experiments previously limited by technological constraints.

This capability facilitates detailed simulations of materials science problems specifically modelling how electrons behave within complex solids using programmable Hubbard models. The innovation lies in creating light patterns exceeding eighty-four million alterations per second alongside precise intensity management; brightness is controlled to within one thousandth of its full value and spatial resolution spans an array of beams. Consequently, scientists can now fully program simulations mirroring material behaviour with Hubbard models and explore error correction techniques demanding rapid atom rearrangement without compromising experimental fidelity.

The researchers developed a new optical system for manipulating ultracold atoms that achieves high precision and speed. This allows for the creation of dynamic arrangements of atoms with intensity control down to one part in a thousand and frame rates above 84 megapixels per second. Authors suggest this architecture unlocks experiments previously limited by existing technologies, offering greater flexibility in controlling atomic interactions and exploring quantum phenomena.

👉 More information
🗞 Ultrafast and high resolution spatial light modulation for cold atoms
✍️ Alexander Dennisovich Deters, Yanfei Li, Alexander Douglas, Markus Greiner and Aaron W. Young
🧠 ArXiv: https://arxiv.org/abs/2608.18071
