Critical States Boost Measurement Precision Beyond Current Quantum Limits

A new framework, criticality-assisted noncommutative preparation (CANP), improves the precision of measurements by utilising critical evolution for state preparation. Ningxin Kong and colleagues at Peking University, in collaboration with Hefei National Laboratory and Shanxi University, developed CANP to overcome limitations in existing methods caused by restricted parameters and operating conditions. The noncommutativity between preparation and encoding operations genuinely enhances the quantum Fisher information, potentially achieving improvements at a fixed sensing time and energy cost. This enhancement, quantified by the Wigner-Yanase skew information, scales similarly to the quantum Fisher information, establishing CANP as a key technique for criticality-enhanced quantum metrology

CANP enhances parameter estimation in quantum systems near criticality

The criticality-assisted noncommutative preparation protocol (CANP) proves effective in the quantum Rabi and Lipkin-Meshkov-Glick models, establishing it as a strong technique to implement criticality-enhanced quantum metrology. In quantum metrology, precise estimation of relevant parameters is achieved by exploiting inherently quantum features as resources. Beyond superposition and entanglement, quantum criticality has recently emerged as a powerful resource for sensing, owing to the extreme sensitivity of systems near a critical point to small variations in physical parameters.

Previously, criticality has been used to probe quantities directly linked to the proximity of systems to the critical point, yielding sharp enhancements but subject to inherent limitations. The set of estimable parameters is restricted by the structure of the critical Hamiltonian, typically limited to quantities such as coupling strengths or mode frequencies, and operating at or near criticality narrows the accessible estimation range. These constraints fundamentally limit the flexibility and broader applicability of criticality-enhanced quantum metrology.

Recognising noncommutativity among quantum operations as another important resource to enhance metrological precision, scientists have explored how noncommutative dynamics may be exploited to improve parameter encoding, enabling sensitivity enhancements inaccessible to commuting operations. Despite these advances, the interaction between criticality and noncommutativity remained largely unexplored until now. A technique, termed criticality-assisted noncommutative preparation protocol (CANP), introduces a probe state first prepared by a critical unitary evolution Uc, and subsequently undergoes parameter encoding via unitary Uθ. This approach uses critical evolution as a state-preparation resource, differing from critically-based metrology protocols.

A general analytical framework is developed, identifying the algebraic conditions required to make criticality-assisted enhancement successful. The noncommutativity between the prepared state and encoding Hamiltonians yields a substantial enhancement of the quantum Fisher information (QFI), enabling improved sensitivity without increasing the total sensing time or energy cost. This effect is quantitatively captured by the Wigner, Yanase skew information, which faithfully tracks the noncommutative structure of the protocol.

This quantity exhibits the same behaviour as the QFI, both in the period of oscillations and in the location of the maxima. Using the example of frequency estimation in the quantum Rabi model, the improvement in precision is shown, and realistic quadrature measurements can be employed to achieve performance close to the CANP-enhanced quantum Cramér, Rao bound. Relocating the critical Hamiltonian from encoding to preparation naturally enlarges the class of accessible parameters beyond those contained in the original critical Hamiltonian and lifts the restriction of a narrow effective estimation range associated with critical conditions, thus broadening the scope of critical metrology.

A general quantum metrological protocol consists of four parts: the preparation of a probe state ρ0, the encoding of an unknown parameter θ onto the probe, the measurement of an observable on the parameterised state ρ0(θ), and the final data processing to extract the estimated value of θ. For a pure probe ρ0, the QFI quantifying the distinguishability between neighboring parameterised states is given by F0(θ) = Var[h0]ρ0, where h0 = i U†θ∂θ Uθ is the local generator of the encoding process, and Var[·]ρ0 denotes the variance with respect to the probe state ρ0. A preparation Hamiltonian Hc that features quantum criticality is first used to evolve the initial state ρ. The preparation dynamics are required to satisfy the noncommutative algebraic relation [ Hc, Γ] = √ ∆Γ, where Γ = −i √ ∆C + D with C = i[ Hc, Hθ] and D = [ Hc, [ Hc, Hθ]]. The critical parameter ∆, determined solely by the intrinsic properties of the critical Hamiltonian Hc, quantifies the proximity to the critical point. The unknown parameter θ does not, in principle, enter either the critical Hamiltonian Hc or the criticality parameter ∆, allowing the CANP protocol to bypass the conventional trade-off in critical metrology, where the parameter of interest is directly tied to the critical behaviour of the system. This algebraic structure enables a closed-form expression for the local generator of parameter translations, h = i U†c U†θ∂θ Uθ Uc, which evaluates to: h = tθ( Hθ + sin( √ ∆tc) √ ∆ C + cos( √ ∆tc) −1 ∆ D). For preparation times tc ∼O, the generator exhibits a sharp amplification as ∆→0, reflecting the emergence of critical dynamics during the preparation stage.

From this equation, the corresponding QFI is given by F(θ) ≃4t2 θ [cos( √ ∆tc) −1]2 ∆Var[ D]ρ. In the regime ∆→0 with a finite preparation time tc ∼O, it yields the scaling F(θ) ∼t2 θt4 c, revealing a sensitivity enhancement at finite tc compared with the conventional t2 θ behaviour and enabling accelerated precision growth without prolonging critical evolution. By contrast, when the preparation time becomes sufficiently long, tc ∼ π/ √ ∆, the leading contribution leads to the divergent scaling F(θ) ∼16∆−2t2 θ, reflecting a critical enhancement upon approaching the critical point. These enhancements arise from the noncommutative structure of the protocol and persist for any initial state ρ satisfying Var[ D]ρ ≃O, thereby eliminating the need for ground state preparation.

To assess the metrological gain arising from the CANP under fair resource constraints, the QFI enhancement ratio R(θ) = F(θ)/F0(θ) is evaluated while fixing both the available energy and the total sensing time. Without loss of generality, frequency estimation with Hθ = a†an is considered, and the probe is taken to be a coherent state, ρ = |α⟩⟨α|. For the conventional directly-encoding scheme, the QFI simplifies to F0(θ) = 4T 2|α0|2, independent of θ. To ensure a fair comparison between the two schemes, it is required that the two final states, whether the critical-preparation is applied, carry the same average energy, ⟨α0|Ωa†a|α0⟩= ⟨α|( U†c U†θ)Ωa†a( Uθ Uc)|α⟩, where Ωdenotes the bosonic mode frequency. Both schemes are constrained to operate with the same total sensing time T = tc + tθ. This condition leads to |α0|2 = ⟨α|( U†c U†θ)a†a( Uθ Uc)|α⟩. For nonvacuum probes α = 0, the ratio R(θ) reads as follows R(θ) = F(θ) 4(tc + tθ)2⟨α|( U†c U†θ)a†a( Uθ Uc)|α⟩. If R(θ) > 1, critical-assisted noncommutative preparation yields a genuine sensitivity enhancement under equal energy and time resources, indicating that the CANP achieves higher precision per initial excitation in terms of energy efficiency.

To quantitatively characterise the noncommutativity underlying the CANP protocol, the Wigner, Yanase skew information is employed, which provides a quantitative measure of the noncommutativity between a quantum state and an observable. It is defined as S = −1 Try([ √ B, K]2), where B is a positive operator and K is a Hermitian operator. Quantum criticality is a resource for quantum-enhanced metrology, but existing schemes face intrinsic limitations. These limitations arise because using criticality directly in the encoding dynamics restricts estimable parameters to those supported by the critical Hamiltonian, and the requirement for critical conditions narrows the effective estimation range.

To address this, a general framework termed criticality-assisted noncommutative preparation (CANP) has been introduced. In this approach, critical evolution serves as a state-preparation resource. The underlying algebraic conditions are established, demonstrating that intrinsic noncommutativity between the preparation and encoding operations leads to a genuine enhancement of the quantum Fisher information (QFI). This enhancement may be achieved at fixed total sensing time and energy cost.

The effect is quantified by the Wigner-Yanase skew information, which measures noncommutativity and exhibits the same critical scaling as the QFI. Effective use of CANP is demonstrated in the quantum Rabi and Lipkin-Meshkov-Glick models. These results establish CANP as a technique to implement criticality-enhanced quantum metrology. As an illustrative example of the CANP scheme, the quantum Rabi model is taken as the critical preparation Hamiltonian, which is a paradigmatic system in quantum optics where a spin interacts with a single bosonic mode.

The Hamiltonian, HRabi = ωa†a + ω0 2 σ(q) z −λ(a+a†)σ(q) x, exhibits a normal-to-superradiant quantum phase transition, making it an ideal platform for criticality-assisted state preparation. Here, σ(q) x,z denote Pauli operators of the qubit with transition frequency ω0, while a (a†) are the annihilation (creation) operators of the field mode with frequency ω, and λ is the coupling parameter. Quantum criticality provides a basis for quantum-enhanced metrology, yet current methods have intrinsic limitations.

These limitations stem from restricting accessible parameters to those within the critical Hamiltonian when using criticality in the encoding dynamics, and the need for critical conditions narrows the estimation range. To address this, a general framework termed criticality-assisted noncommutative preparation (CANP) is introduced. This approach utilises critical evolution as a resource for state preparation. The underlying algebraic conditions are established, demonstrating that noncommutativity between the preparation and encoding operations genuinely enhances the quantum Fisher information (QFI). This enhancement can be achieved with fixed sensing time and energy expenditure. The effect is quantified by the Wigner-Yanase skew information, which measures noncommutativity and shares the same critical scaling as the QFI. Effective implementation of CANP is demonstrated in the quantum Rabi and Lipkin-Meshkov-Glick models, establishing it as a technique for criticality-enhanced quantum metrology.

Utilising quantum criticality for sensor preparation unlocks broader measurement capabilities

Scientists are refining techniques to squeeze more precision from quantum sensors, vital for applications ranging from medical imaging to gravitational wave detection. Current approaches use quantum criticality, the point at which materials undergo dramatic changes, to amplify sensitivity, but these rely on directly embedding criticality within the sensing process itself. This limits the range of measurable parameters and the conditions under which optimal performance can be achieved.

To overcome these limitations, scientists have developed a new framework, criticality-assisted noncommutative preparation, which uses quantum criticality as a preparatory resource rather than directly within the measurement. This new approach bypasses previous restrictions, potentially enhancing precision without increasing energy demands. Researchers have demonstrated that by exploiting the inherent noncommutativity between state preparation and parameter encoding, a genuine boost to the quantum Fisher information can be achieved.

Scientists demonstrated a new method for enhancing quantum metrology using quantum criticality as a state-preparation resource. This criticality-assisted noncommutative preparation technique improves upon existing schemes by decoupling criticality from the sensing process itself, broadening the range of measurable parameters. The research shows that noncommutativity between preparation and encoding operations genuinely enhances the quantum Fisher information, potentially at a fixed energy cost. Researchers validated this approach using the quantum Rabi and Lipkin-Meshkov-Glick models, establishing it as a robust technique for criticality-enhanced quantum sensing.
