Researchers boost Verilog debugging with ARSP, achieving 83.88% accuracy and reducing signal dilution

Fixing errors in complex digital designs written in Verilog currently demands considerable time and effort from engineers, but new research offers a promising automated solution. Bingkun Yao, Ning Wang, and Xiangfeng Liu, all from City University of Hong Kong, alongside colleagues, present a system called ARSP that significantly improves the ability of artificial intelligence to automatically repair these designs. The team addresses a key limitation of current AI-powered debugging tools, their struggle with large, complex code, by intelligently breaking down the design into smaller, more manageable fragments based on their semantic meaning. This approach, which focuses the AI’s attention on relevant sections of code, demonstrably outperforms both leading commercial AI models and state-of-the-art automated debugging tools, achieving a substantial increase in successful repair rates and offering a potential pathway to dramatically accelerate the design process.

LLMs Repair Verilog Designs via Partitioning

This document presents an overview of recent research exploring the use of Large Language Models (LLMs) for Verilog hardware description language (HDL), specifically focusing on code generation, debugging, and repair. Researchers are actively investigating how LLMs can automate Verilog tasks, with studies exploring code generation from specifications, bug identification, and automated repair. This research demonstrates that LLMs hold significant promise for automating various stages of Verilog hardware design and verification, despite challenges posed by the complexity of Verilog code. Several studies focus on addressing limitations of LLMs, such as generating incorrect code and a lack of understanding of hardware constraints.

Researchers are exploring multi-modal approaches, combining LLMs with techniques like formal verification to improve reliability, and investigating methods for fine-tuning LLMs specifically for Verilog tasks, including specialized datasets and reinforcement learning techniques. These advancements aim to enhance the accuracy and efficiency of LLM-based tools for Verilog design. Key takeaways from this research include the potential of LLMs to automate Verilog tasks, the importance of semantic understanding in breaking down complex designs, and the need to address LLM limitations. The field is rapidly evolving, with new research constantly pushing the boundaries of what’s possible with LLMs in hardware design.

Semantic Partitioning and LLM-Based Verilog Debugging

Researchers developed ARSP, a novel system for automated Verilog debugging that addresses the problem of diluted error signals in large hardware modules. Recognizing that bugs are often localized, the team hypothesized that dividing a module into semantically cohesive fragments would allow a Large Language Model (LLM) to focus more effectively on the relevant code. Consequently, ARSP employs a two-stage approach, beginning with a Partition LLM that intelligently splits a Verilog module into these fragments based on semantic relationships within the code. This fragmentation is followed by a Repair LLM, specifically trained to generate patches for each individual fragment, enabling focused debugging and minimizing the impact of irrelevant code.

Semantic Fragmentation Improves Verilog Debugging Performance

Researchers have developed a novel system, ARSP, to significantly improve the automated debugging of Verilog hardware descriptions, a critical step in front-end design. The team addressed the challenge of “bug signal dilution,” where important error information gets lost within lengthy code blocks, hindering the effectiveness of large language models (LLMs). ARSP overcomes this limitation through a two-stage process involving semantic fragmentation, effectively breaking down complex modules into smaller, more manageable pieces. The core of ARSP lies in its ability to partition Verilog code into “semantic tight fragments,” ensuring each fragment represents a logically coherent unit of functionality.

This partitioning process, guided by LLMs and validated through a robust voting mechanism, results in an average of 6. 34 fragments per module, with each fragment containing approximately 32. 16 lines of code, representing 15. 72% of the original code. Experiments demonstrate that this semantic partitioning improves debugging performance by 11.

88%, surpassing the performance of both mainstream commercial LLMs like Claude-3. 7 and state-of-the-art automated Verilog debugging tools such as Strider and MEIC. A key innovation involves a correction mechanism that ensures fragments accurately reflect the original code structure, achieving 90% correction accuracy and maintaining semantic integrity. This breakthrough delivers a substantial advancement in automated hardware debugging, promising to reduce design time and improve the reliability of complex digital systems.

Fragmented Verilog Improves LLM Debugging Performance

The research presents ARSP, a novel two-stage system designed to improve the automated debugging of functional Verilog code using large language models. Recognizing that existing LLM-based methods struggle with the complexity of industrial-scale modules due to signal dilution in long contexts, ARSP mitigates this issue by first fragmenting the code into semantically coherent units. A separate LLM then focuses on repairing each fragment individually, before merging the edits without affecting unrelated logic. This approach demonstrably improves debugging performance, achieving higher pass rates on challenging test sets compared to both commercial LLMs and state-of-the-art automated debugging tools.

The team also developed a synthetic data framework to generate a more robust training dataset, addressing the limited scale and complexity of existing benchmarks. By strategically injecting common functional bugs into correct code, and expanding the dataset iteratively, they created a resource better suited to training LLMs for real-world Verilog debugging tasks. Experiments confirm that semantic partitioning significantly enhances debugging accuracy, validating the effectiveness of focusing on smaller, logically organized code sections.
